2022 Merida eOne Sixty 700
The new eONE-SIXTY once again embodies e-enduro bikes, instead of the normally needed shuttle to session your favourite tracks, you have your own built-in engine to assist you to the top. On downhills, it still feels like a normal bike, agile due to its perfectly tuned MTB geometry, but more planted because of the higher weight. All in all, it’s a super fun bike with a clear focus on trail riding. But the last few years have shown that our eONE-SIXTY is also often used as a kind of 'SUV' bike. Because of the advantages of more travel, bigger tyres and comfortable geometry, it also shines away from the enduro tracks and offers a super fun, comfortable and capable alternative to a ‘normal’ mountain bike.
Frame: eONE-SIXTY LITE III; MAT aluminium; 150 STR; 27.5x2.8" max. WHS; 148x12 AST; intube
Sizes: XS-S-M-L-XL
Fork: Marzocchi Z1 Ebike+; Air; 160 STR; Tapered; 51mm fork offset; 29x2.6" max WHS
Rear Shock: FOX Float DPX2 Performance; platform
Drive Unit: Shimano DU-EP600, 85Nm
Battery: Shimano EN806 630Wh / Shimano EN805 504Wh for XS only
Battery Charger: Shimano EC-E8004; 4A charging current
Display: Shimano SC-EN600
Mode Switch: Shimano SW-EN600-L
Rear Derailleur: Shimano XT RDM8100 Shadow+ 12
Shifters: Shimano DEORE M6100 12
Dropper Post Lever: Shimano SL -MT500-IL
Brake-F: Shimano SLX; 4 piston
Brake-R: Shimano SLX; 4 piston
Rotor-F: Shimano RT64; 203 mm
Rotor-R: Shimano RTEM600; 203 mm
Chainring: Shimano CRE80-12-B; 34 ATC
Crank: Shimano FCEM600; 165 mm for all sizes
Chain: KMC e12T EPT
Cassette: Shimano M6100; 10-51 ATC; 12 GER
Pedals: VP VPE-527
Handlebar: MERIDA EXPERT eTR; 780 WHB; 20 RHB
Handlebar Stem: MERIDA EXPERT eTR II; MAT aluminium; 35 DSH; 0 ASD; Supernova mount
Stem Length: 40 mm all sizes
Seat Post: MERIDA EXPERT TR; 30.9 DSP; 0 SSB; XS 100 SPT - S 125 SPT - M/L 150 SPT - XL 170 SPT
Saddle: MERIDA EXPERT CC; V-mount
Hub-F: Shimano SLX; 110x15 WHF; 32 SPH; Centerlock
Hub-R: Shimano SLX; 148x12 WHR, 36 SPH; Centerlock
Axle-R: MERIDA EXPERT TR; including removeable lever, 6/4mm allen key
Rims: MERIDA EXPERT TR; 29 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included)
Tyre-F: Maxxis Assegai; 29x2.5 "; fold; TR EXO+ 3C MaxxGrip
Tyre-R: Maxxis DHR II; 27.5x2.6 "; fold; 3C EXO+ TR
Light Front: LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount
Light Rear: USB REAR Light CG-214RG
Other: MERIDA Multitool with saddlebox
Max Rider Weight: 140kg
Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas.
