2026 Scott Scale Gravel 10
The Scale Gravel was put on this planet for going on adventures with attitude. Designed to go the distance over any and all types of terrain, the Scale Gravel is lightweight with agile handling and features multiple mounting options.
Frame: Scale Carbon HMF, Adjustable head angle, Syncros Cable Integration System, Advanced Shock & Standing Damping System, BB92, UDH Interface, 12x148mm with 55mm Chainline
Fork: Scale Rigid HMF, Postmount Disc Standard, Tapered Carbon steerer
Headset: Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Rear Derailleur: SRAM S1000 Eagle AXS 12 Speed, Wireless Electronic Shift System
Shifters: SRAM AXS Pod Controller
Brakes: SRAM DB6 4-Piston Disc
Crankset: SRAM Eagle 70 Transmission, DUB, 55mm CL, 34T
Chainguide: SCOTT custom
BB-Set: SRAM DUB PF 92 MTB Wide, shell 41x92mm
Handlebar: Syncros Fraser 2.0 XC Alloy 6061 D.B., Flat Bar, 8°, 740mm, Syncros Performance XC lock-on grips
H'stem: Syncros XC 2.0, Syncros Cable Integration System, -12° rise, 6061 Alloy, 31.8mm, 1 1/8"
Seatpost: Syncros Duncan 2.0, 10mm offset, 31.6x400mm
Seat: Syncros Belcarra V2.0 Cut Out, CRMO rails
Front Hub: Formula CL-811, 15x110mm
Rear Hub: Formula CL-3248, 12x148mm
Chain: SRAM CN Eagle 70 Transmission
Cassette: SRAM Eagle XS 1270 V2 Transmission 10-52
Spokes: Stainless Black 15G, 1.8mm
Rims: Syncros X-28, 28H, Tubeless ready
Extras: SRAM AXS Powerpack
Accessories: Spirgrips+ Inner Bar ends
Approx weight in KG: 10.5 (Tubless setup)
Approx weight in LBS: 23.15 (Tubless setup)
Rotor: SRAM Centerline CL Rotors 180/F and 160/R
Front Tire: Maxxis Aspen, 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO
Rear Tire: Maxxis Aspen, 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO
Max. System Weight: 120kg
