DT Swiss ER 1600 Spline 32 Tubeless Disc Road Wheel
No frills- just the best components. For maximum performance at great value.
Deviating from the planned track to discover that little bumpy side road to your left. Tackling the next descent with full speed and maximum control- despite the tarmac not meeting Formula-One criteria: This light and welted rimset, available with a 23 or 32mm height, strong spokes and a precise and reliable 350 hub, truly lives up to its full potential once the road surface gets worse- while still transforming every watt into forward traction. At any time.
REAR WHEEL | FRONT WHEEL | |
GENERAL | ||
NET WEIGHT | 948 g | 819 g |
RECOMMENDED SYSTEM WEIGHT MAX. | 130 kg | 130 kg |
ASTM CLASSIFICATION | 2 | 2 |
RIM | ||
MATERIAL | Aluminum | Aluminum |
RIM JOINT | Welded | Welded |
TIRE INTERFACE | Hooked / Crotchet tubeless TC | Hooked / Crotchet tubeless TC |
VALVE HOLE | Presta | Presta |
RIM DIAMETER | 29" / 700C | 29" / 700C |
RIM HEIGHT | 32 mm | 32 mm |
DECAL TYPE | Waterslide | Waterslide |
INNER WIDTH | 20 mm | 20 mm |
OUTER WIDTH | 24 mm | 24 mm |
HUB | ||
HUB TYPE | 350 | 350 |
AXLE SYSTEM | 12 mm Thru Axle | 12 mm Thru Axle |
BUILT-IN DIMENSION | 142 mm | 100 mm |
BRAKE INTERFACE | Disc Center Lock | Disc Center Lock |
FREEHUB BODY | Shim. RD. 11SP Forged (ASF11) | - |
FREEHUB SYSTEM | Ratchet System 18 | - |
SPOKES & NIPPLES | ||
SPOKES LEFT | DT aero comp® wide straightpull | DT aero comp® wide straightpull |
SPOKES RIGHT | DT new aero® Straightpull | DT aero comp® wide straightpull |
SPOKE PATTERN | Two-cross (1:1) | Two-cross (1:1) |
NIPPLES | DT Prolock Squorx ProHead alu | DT Prolock Squorx ProHead alu |
INCLUSIVE | ||
Tubeless tape 23 mm | Tubeless tape 23 mm | |
Tubeless valve road 32 mm | Tubeless valve road 32 mm | |
IS 6-bolt adapter Road | IS 6-bolt adapter Road | |
5 mm endcap Kit | 5 mm endcap Kit | |
15 mm endcap kit | ||
